Answer in brief
There is no sound universal price for a zero-point clamping system. First define what the system must include. Then place each part, task, test and trade term on one budget sheet. Quotes are ready to compare only when they cover the same models, amounts, duties and limits. This page shows how to build that sheet. It does not give guessed prices.
“Zero-point system” can describe one receiver on a machine table. It can also describe a plate, several receivers, mating studs, upper fixtures, air service, sensors and site work. Both uses are valid. They are not the same buying scope.
A ballpark figure hides that gap. It can leave a buyer with too little money for the full stack, or make a simple need look larger than it is. A better budget starts as a list. Every blank must become included, optional, excluded or unknown before approval.
Pass the technical gate before you set the budget
A low total is not useful if the chosen parts cannot support the job. Close the first technical questions before asking for a firm quote. Share the machine table drawing, part and fixture files, total moving load, support plan, cutting loads, planned pallet count and service needs.
The supplier should name the exact receiver and mating parts. Ask for the current interface drawings. Check mounting, pull-stud or mating detail, release access, tool path, probe path and the full load through the stack. If air or signals are planned, show their source and route. Mark each point that still needs proof.
The zero-point system RFQ guide covers that model and interface review. Use it first when the technical layout is not fixed. This cost guide begins once at least one exact scope is plausible.
Draw the system boundary
Start with a simple block drawing from the machine table to the workpiece. Give each layer a name and owner. The stack may include the table mount, adapter, receiver, mating part, pallet or fixture plate, upper fixture and workpiece. Do not merge these into one line called “zero-point system.”
Next, draw the service boundary. Show valves, hoses, fittings, filters, sensors, cables, control inputs, outputs and any site connection. Add the work boundary too: design review, plate machining, mounting, wiring, start-up, training, trial parts and acceptance records.
This boundary prevents a common quote gap. One supplier may include a finished plate and start-up. Another may quote receiver hardware only. Their totals cannot be compared until the sheet shows who owns each missing layer and task.
Build the budget line by line
| Budget group | Name on the sheet | Scope proof to request |
|---|---|---|
| Machine-side hardware | Receiver model and amount | Model code, drawing issue and mount detail |
| Mating hardware | Stud, nipple or mating interface by model | Matched drawing and amount per pallet or fixture |
| Base and plate work | Base, adapter, pallet or fixture plate | Material, finished state, machining owner and drawing |
| Air and control | Valve, line, fitting, sensor, cable and I/O work | Circuit, signal list and site boundary |
| Site work | Mount, wire, set up, train and start | Task owner, location, access and completion record |
| Proof and records | Checks, reports, manuals and drawing pack | Method, pass rule, format and language |
| Support | Spares, tools and planned service | Part list, lead time and support limit |
| Trade terms | Freight, tax, currency, delivery and payment | Named term, date, place and quote validity |
Add a unique line for each item that can change by model, amount or owner. A plate is not the same as plate machining. A sensor is not the same as wiring it into the machine. A test is not the same as a signed report. Separate lines make later changes clear.
Use an exact model and amount schedule
Do not write “receiver set” if more detail is known. Give the model, drawing issue, amount and location. Tie each mating part to the receiver it serves. Give each plate or upper fixture its own row. If the final model is not known, mark it as unknown and name the test or drawing needed to close it.
Use an amount basis that a second reviewer can follow. State the amount per machine, per station, per pallet, per fixture and for the whole project. This stops one quote from showing a per-machine amount while another shows a plant total.
Also separate production parts from spares. A spare may be sensible, but it is not an installed station. Name special tools, seal kits and other support parts as their own rows. The buyer can then choose them without changing the base system count.
Keep included, optional, excluded and unknown apart
Every budget line needs one clear status. Included means the supplier gives that item or task under the shown total. Optional means it has a named line and can be selected. Excluded means the supplier will not provide it. Unknown means the answer has not yet been set.
These words are not equal. An unknown line may later add work. An excluded line still needs an owner. An optional line needs a valid choice and a clear effect on the scope. An empty cell has no safe meaning, so do not treat it as included.
Add an assumption column beside the status. Good assumptions are plain and testable. They may state that the buyer provides clean air at a named handoff point, or that the supplier receives an approved plate drawing before work begins. Ask who closes each assumption and by what date.
Normalize quotes before you compare totals
Copy each supplier quote into one common table. Keep the supplier wording in a notes field, but map the item to your own scope row. Compare the same model duty, amount basis, work boundary, proof and trade term.
| Check | Question for each quote | Action if different |
|---|---|---|
| Technical duty | Is the same part, load, stack and service case covered? | Pause the total comparison and close the technical gap. |
| Models and amounts | Are exact models and the same project amounts shown? | Map both to the model and amount schedule. |
| Work boundary | Who designs, machines, mounts, wires and starts the system? | Add the missing task and owner to the budget. |
| Proof | Are the same checks, pass rules and records included? | Request the same proof or mark the gap. |
| Trade basis | Do currency, freight, tax, delivery and payment terms match? | Restate both on one approved basis. |
Do not “correct” a quote with a guessed line value. Keep the gap visible and ask for a new line. If the supplier cannot define it yet, leave it unknown and add a budget hold owned by the buyer. The sheet should show what is known, not hide doubt behind a neat total.
Lock the commercial basis
A quote total needs a date and basis. Record the currency, tax treatment, freight term, ship-to place, packing, payment steps, delivery plan and validity date. State whether travel, lodging, import fees, local lifting and machine access are included or owned by the buyer.
Delivery wording also needs a clear event. “Lead time” may start at order, drawing approval, receipt of sample parts or another gate. Ask the supplier to name that gate and the items that can pause the plan. Keep staged deliveries on separate rows when hardware and site work do not arrive together.
For a revised quote, keep the older issue and mark what changed. A model change, amount change or new exclusion can move the total for a sound reason. A short change note lets finance and engineering review the same facts.
Turn the budget into a firm quote request
Send one scope pack to each supplier. Include the machine model and table drawing, part and fixture files, load and support plan, expected machine and pallet count, air and signal plan, target checks, document list, spare needs and ship-to details. Add the model schedule and budget table.
Ask the supplier to return the same sheet with model codes, amounts, status, assumptions, work boundary, delivery basis and total. Require each exception to be written next to the affected line. This makes the answer easy to review and useful for later change control.
Do not ask the quote to prove fit by itself. Engineering still needs to approve the interface, load path, services and test plan. The quote records what will be supplied. The drawings and acceptance plan record what must work.
Build a quote-ready scope
Send the machine, part, stack, amount and service plan. NEXTAS can return a model-based scope with included, optional, excluded and unknown lines.
Request a scoped quoteFrequently asked questions
Why is there no universal price for a zero-point system?
Because a system can mean one receiver or a full machine-side stack. The quote changes with the exact models, quantities, interfaces, plates, services, controls, documents, tests, spares and trade terms. A useful budget starts with that scope, not a market average.
What should a zero-point system quote include?
List each receiver, mating stud or interface, base or adapter plate, fixture or pallet, valve and service part, sensor and control item, mount and start-up task, test, document, spare and commercial term. Mark who supplies and accepts each line.
Does adding more stations always increase the quote in the same way?
No. A station may repeat an existing receiver, but it can also change the plate, plumbing, sensing, cable route, machine clearance or test plan. Compare the new full bill and integration work instead of multiplying a single unit line.
How can I compare two zero-point system quotes fairly?
Put both quotes into one table with the same model, quantity, interface, service, test, document, delivery and trade-term columns. Mark included, optional, excluded and unknown items. Ask each supplier to close the same gaps before you compare totals.
What belongs in the unknown, optional and excluded columns?
Unknown means the scope is not yet defined. Optional means it has a named line and can be chosen. Excluded means the supplier will not provide it. Keep these separate so an empty cell is never mistaken for an included part.
What should I send to get a firm quote?
Send the machine model and table drawing, part and fixture files, load and support plan, required receiver and pallet count, planned services and signals, target checks, documents, spare needs, ship-to location and requested trade terms. Ask the supplier to state every assumption.
